Blackline Safety Lone Worker Protection

Gadgets don’t save lives, people do!

We help corporates, businesses & governments with remote workers stay in touch & get help fast should they need it no matter where they are working. We do this using Blackline Safety wearable solutions with 24/7 monitoring.

Blackline Safety is based in Canada and have some of the most sophisticated Lone Worker duress devices. The Blackline Portal on which the devices are managed, is intuitive and offers a great selection of automated reports and easy exception based analysis of device use and alert management.

The Blackline Safety Solutions are integrated via API to our Guardian Angel monitoring station in in country. This means when the alerts hit their servers, it also hits our response software.

To top it off, we find them proactive and engaging to deal with which produces better results for our customers too.

Gain real-time visibility of the wellbeing of your teams and ultimate command over your connected safety fleet with our cloud-based software platform, Blackline Live.

Log in to your account (included with every Blackline device purchase) and effortlessly configure, assign, monitor and manage your wearable personal gas detection, lone worker and area monitoring equipment—from anywhere you have Internet access.

See your entire fleet on a single screen with the live map view. Simply log in and valuable situational information from all your devices is available at your fingertips at once.

If an alert is received, easily view the type, status, and location in real-time to help quickly find a worker in distress and understand the hazards they face.

Our in country monitoring station personnel use Blackline Live to gather critical insights and manage emergency alerts in real-time.

Blackline Live Monitoring Portal

Blackline Safety Devices

G7x + G7 Bridge

G7x

A hybrid bridge and pendant solution which offers protection everywhere for every risk; iridium and cell cover, SOS, fall alert, impact and no movement alerts, works inside from pendant to bridge with a 2km radius (terrain dependant), two way SMS messaging, automated welfare checks. We have a range of Lone Workers relying on this from Animal Control staff to community nurses and utility companies.

This device can also be fitted with Gas Detection kit for enclosed spaces and other environments where GAS leaks may be a risk.

Features

  • Fall detection and No-motion detection: Tri-axis accelerometer, tri-axis gyro, software processing, configurable sensitivity, configurable time window (1-30 mins, or off ) for no-motion detection
  • SOS latch: Pull latch to trigger red alert
  • Silent SOS: Press and hold latch to trigger red alert
  • Low-battery: Configurable threshold
  • Worker check-in: Configurable timer (5–180 min, or off ), automatic check-in when driving
Size & weight

G7 with Standard Cartridge
Size: 64 mm x 124 mm x 27 mm (2.52” x 4.88” x 1.06”)
Weight: 162 g (5.7 oz)

G7 with Single-gas Cartridge
Size: 64 mm x 128 mm x 27 mm (2.52” x 5.04” x 1.06”)
Weight: 167 g (5.9 oz)

G7 with Quad-gas Cartridge
Size: 66 mm x 150 mm x 27 mm (2.52” x 5.91” x 1.06”)
Weight: 192 g (6.8 oz)

Single-gas & Quad-gas Sensor OptionsH2S, LEL, CO/CO-H, O2, NH3, SO2
Coming soon : Cl2, COSH, CO2, LEL-Pellistor, PID
User interface168 by 144 pixel graphical, high contrast, liquid crystal display with front lighting, menu system driven by a three-button keypad, power button (on/ off ), check-in button (check-in/silent SOS), SOS latch (send emergency alert)
User notification

Green SureSafe® light: Blinking (powered), continuous (connected)
Yellow top and front lights: Yellow pending alarm and yellow warning alarm
Red top and front lights: Red alert communicated
Blue LiveResponse™ top and front lights: Confirmation that alert has been acknowledged Alarm Indicators: Speaker, LEDs and vibration motor

G7x Wireless Radio
Works with G7 bridge satellite base stationRadio: 902.0–928.0 MHz, 1 Watt
Antenna: Internal
Radio link range: 2 km (1.25 mi) real-world
Location technologyGPS Radio: 48-channel high sensitivity
Assisted-GPS: Yes
GPS Accuracy: ~5 m (16 ft) Outdoors
Indoor location technology: Blackline Safety location beacons
Location update frequency: 15 min
Power & batteryRechargeable Li-ion battery: 1250 mAh
Li-ion Battery Life: 18 hours continuous operation at 20° C (68° F)
Charge time: 4 hours
EnvironmentalStorage temperature: -30°C to 75°C (-22°F to 167°F) Operating temperature: -20°C to 55°C (-4°F to 131°F)
Charging temperature: 0°C to 45°C (32°F to 113°F)
Ingress Protection: IP67
WarrantyG7: two years
Cartridges: Lifetime
G7 complete plan: three years
Wireless updatesDevice configuration changes: Yes
Device firmware upgrade over-the-air (FOTA): Yes
Approvals

SAR, RoHS, RCM
FCC ID: W77G7X | IC ID: 8255A-G7X
Canada and USA: Class I Division 1 Gr A,B,C,D T4; Class I Zone 0 AEx ia IIC T4; Ex ia IIC T4 Ga image IECEx: Ex ib IIC T4 Gb
LEL-NDIR: -20°C to 45°C ; CSA C22.2 No.152; ISA 12.13.01
LEL-Pellistor: Ex ia IIB T4 Ga; Ex ib IIC T4 Gb

Pending Approvals
LEL-Pellistor: Ex ia IIC T4 Ga; CSA C22.2 No. 152; ISA 12.13.01

G7 Bridge
Size & weightSize: 73 mm x 107 mm x 141 mm (2.87”x 4.21”x 5.55”)
Measurements do not include mount
Weight: 540 g (19.04 oz)
Wireless communicationRadio: UMTS 800/850/900/1900/2100; Quad-band GSM/GPRS 850, 900, 1800, 1900; Iridium Satellite (1621 MHz); ISM band radio (915 MHz)
900 MHz Radio: Americas: 902 – 928 MHz
Australian/New Zealand: 916 – 927 MHz, 1 Watt
Antenna: Internal
Power & batteryRechargeable Li-ion battery: 6800 mAh capacity
Battery Life: 50 hours @ 20°C (68°F); 44 hours @ -20°C (-4°F); 14 hours @ -40°C (-40°F); It is recommended that the hard wire kit is used anytime below -20°C
Charging connector: Micro USB
Environmental

Storage temperature: -30°C to 75°C (-22°F to 167°F) Operating temperature: -40°C to 55°C (-40°F to 131°F) Charging temperature: 0°C to 45°C (32°F to 113°F)Ingress Protection: Designed to meet IP65

Regulatory compliance

FCC, IC, RCM, RoHS
Contains: FCCID: XPYICGM5NNN, Q639603, KQNMLINK900, IC: 8595A-ICGM5NNN, 4629A-9603, 2361A-MLINK900

900MHz radio link range

General use: up to 2 km

G7c

G7c

A cell based duress pendent worn on the person. Functions include; SOS, fall alert, impact and no movement alerts, two way voice, automated welfare checks. This device can also be fitted with Gas Detection kit for enclosed spaces and other environments where GAS leaks may be a risk.

Features

  • Fall detection and No-motion detection: Tri-axis accelerometer, tri-axis gyro, software processing, configurable sensitivity, configurable time for no-motion
  • SOS latch: Pull latch to trigger SOS alert
  • Silent SOS: Press and hold latch to trigger SOS alert
  • Low-battery: Configurable threshold
  • Worker check-in: Configurable timer (10 min – 180 min, or off ), automatic check-in when driving
Size & weight

G7 with Standard Cartridge
Size: 64 mm x 124 mm x 27 mm (2.5” x 4.9” x 1.1”)
Weight: 162 g (5.7 oz)

G7 with Single-gas Cartridge
Size: 64 mm x 128 mm x 27 mm (2.5” x 5.0” x 1.1”)
Weight: 167 g (5.9 oz)

G7 with Multi-gas diffusion Cartridge
Size: 66 mm x 150 mm x 27 mm (2.5” x 5.9” x 1.1”)
Weight: 192 g (6.8 oz)

G7 with Multi-gas pump Cartridge
Size: 66 mm x 151 mm x 38.5 mm (2.6” x 5.95” x 1.52”)
Weight: 238 g (8.4 oz)

User interface168 by 144 pixel graphical, high contrast, liquid crystal display with front lighting, menu system driven by three-button keypad, power button (on/ off ), check-in button (check-in/silent SOS), SOS latch (send emergency alert)
Multi-language support: Yes, EN, FR, ES, DE, IT, NL, PT
User notification

Green SureSafe® light: Blinking (powered), continuous (connected)
Yellow top and front lights: Yellow pending alarm and yellow warning alarm
Red top and front lights: Red alert communicated
Blue LiveResponse™ top and front lights: Confirmation that a monitoring team has acknowledged the alert
Alarm Indicators: Speaker, LED lights and vibration motor
Speaker sound pressure level: ~95 dB @ 30 cm (~95 dB @ 11.8”)
Voice calling: Speakerphone and phone modes (G7c model only)

G7c + Gas Detection

G7c plus Gas Detection

G7c is the world’s first 3G-connected gas detector with integrated lone worker monitoring and evacuation management tools, connecting workers to live monitoring personnel in real-time. Work-anywhere 3G connectivity is complemented by an industrial two-way speakerphone, text messaging and location tracking.

Devices automatically watch over workers and call for help, even when the employee can’t. G7c delivers comprehensive gas coverage with an exclusive modular design, tailoring gas detection to every industry, application and scenario. Should a gas leak, fall or a no-motion incident be detected, assisted-GPS capability guides responders directly to the effected worker’s location.

Features

  • Fall detection and No-motion detection: Tri-axis accelerometer, tri-axis gyro, software processing, configurable sensitivity, configurable time for no-motion
  • SOS latch: Pull latch to trigger SOS alert
  • Silent SOS: Press and hold latch to trigger SOS alert
  • Low-battery: Configurable threshold
  • Worker check-in: Configurable timer (30 – 180 min, or off ), automatic check-in when driving
  • Time-weighted average (TWA)
  • Short-term exposure limit (STEL)
  • High gas alert
  • Low gas alert
  • Bump test and calibration notification
  • Bump test and calibration failure alert
Size & weight

G7 with Standard Cartridge
Size: 64 mm x 124 mm x 27 mm (2.5” x 4.9” x 1.1”)
Weight: 162 g (5.7 oz)

G7 with Single-gas Cartridge
Size: 64 mm x 128 mm x 27 mm (2.5” x 5.0” x 1.1”)
Weight: 167 g (5.9 oz)

G7 with Multi-gas diffusion Cartridge
Size: 66 mm x 150 mm x 27 mm (2.5” x 5.9” x 1.1”)
Weight: 192 g (6.8 oz)

G7 with Multi-gas pump Cartridge
Size: 66 mm x 151 mm x 38.5 mm (2.6” x 5.95” x 1.52”)
Weight: 238 g (8.4 oz)

User interface168 by 144 pixel graphical, high contrast, liquid crystal display with front lighting, menu system driven by three-button keypad, power button (on/ off ), check-in button (check-in/silent SOS), SOS latch (send emergency alert)
Multi-language support: Yes, EN, FR, ES, DE, IT, NL, PT
User notification

Green SureSafe® light: Blinking (powered), continuous (connected)
Yellow top and front lights: Yellow pending alarm and yellow warning alarm
Red top and front lights: Red alert communicated
Blue LiveResponse™ top and front lights: Confirmation that a monitoring team has acknowledged the alert
Alarm Indicators: Speaker, LED lights and vibration motor
Speaker sound pressure level: ~95 dB @ 30 cm (~95 dB @ 11.8”)
Voice calling: Speakerphone and phone modes (G7c model only)

G7 EXO

G7 EXO

Area monitoring and gas detection that seamlessly connects your site and teams.

The world’s first direct-to-cloud area monitor that delivers ultimate visibility into your entire facility and workforce. With integrated 4G and optional satellite connectivity, G7 EXO automatically links to the Blackline Safety Cloud where it can integrate and work alongside employee-worn G7 devices. Streaming critical insights that create a more engaged, safer workplace across all levels and locations of your business.

Features

  • Longest lasting battery life in the industry — 100+ day run time in standard operating configurations
  • With 4G cellular connectivity, G7 EXO works nearly
  • anywhere in the world
  • Immediate, seamless integration with Blackline Safety Cloud and any number of G7 wearables*
  • Optional push-to-talk works like a walkie-talkie with 100 channels
  • Optional 24/7 live monitoring by Blackline’s in-house Safety Operations Centre
  • Optional four-channel pump module for multi-area monitoring
  • More than 20 gas sensor options
  • Optional satellite module for true global coverage*
  • Simultaneous monitoring of up to five gases
  • Automated configuration changes and firmware updates
  • Automated usage and compliance reporting
  • Rugged exterior stands up to the harshest conditions
  • Integrated GPS and location beacon capability
  • 360º diffusion gas detection
Functional settingsSOS latch: Pull latch to trigger SOS alert
Low-battery: Configurable threshold
Connection lost: Configurable threshold
Two-way messages: Custom messages and 10 preconfigured sent to monitoring personnel
Maintenance code: Configurable 4 digit
Push-to-talk: Send and receive voice messages to other G7 devices
Gas cartridge featuresHigh gas alert
Low gas warning alarm
Under limit (UL)
Over limit alerts (OL)
Bump test and calibration notification
Bump test and calibration failure
Size & weight

Material: Rugged housing built from aluminum, plastic and rubberized bumpers
Size: 385 mm x 188 mm x 220 mm (15.1” x 7.4” x 8.7”)
Weight: 12.25Kg 27 lbs

Wireless updatesDevice configuration changes: Yes
Device firmware upgrade OTA: Yes
Interface portsIntrinsically safe, configurable external signal ports designed to integrate with external alarms and electrical systems.
User interfaceDisplay: : 4.4“ diagonal, 480 by 640 pixel, eightcolour active matrix liquid crystal display
Menu system: driven by three-button keypad
Power button: On/off
SOS latch: Send SOS alert
Multi-language support: (EN, FR, ES, DE, IT, NL, PT)
User notificationGreen connectivity light: Blinking (powered), continuous (connected)
360-degree visible yellow and red lights
Yellow light: Warning alarms
Red light: Alerts
Blue LiveResponse™ indicator light: Confirmation that a monitoring team has acknowledged an alert
Cellular wireless radioWireless coverage: 100 countries, 200 wireless carriers
North America: 3G/4G radio; 3G UMTS bands 2 and 5; 4G bands 2, 4 and 5
International: 2G/4G radio; 2G GSM bands E-GSM and PCS; 4G bands 3, 7 and 20
Asia Pacific: 3G/4G radio; 3G UMTS band 1; 4G bands 3, 8 and 28 Antenna: Internal
Satellite moduleUser-upgradeable satellite module allows EXO to connect to the iridium satellite network for remote areas outside of cellular connectivity
Optional module: Yes
Network: Iridium, global coverage
Radio: 1621 MHz, 2 Watts
Antenna: Internal
Four-channel pump moduleOptional module: Yes
Number of pump channels: 4
Sampling period per channel: Adjustable
Tubing length per channel: Up to 30 m (100 ft)
Size: 18×9.5×8 cm (7×3.7×3.1 in)
Weight: 272 g (0.6 lb)
IS trickle charge portCan be used to hard-wire an IS power supply to run EXO indefinitely
Location technologyMulti-constellation: GPS/QZSS, Galileo, Beidou
Receiver type: 72-channel
Assisted-GNSS: Yes
GNSS Accuracy: 5m (16feet), CEP 50%, 24 hours static
Power & batteryRechargeable battery capacity: 144 Ah (LiFePO4)
Battery life in diffusion mode: 100 days at 20°C (68°F), LEL-IR, H2S, CO and O2 configuration
Battery life in pump mode: 30 days at 20°C (68°F)
Charge time: ~12 hrs
Charge temp.: 0°C to 45°C (32°F to 113°F)
A/B interfaceIntrinsically safe, highly configurable external signal ports designed to integrate with external alarms and electrical systems.
Four pins per interface port
Pin 1: Low side switch Voc=24Vdc, Isc=3.33A, Co=0F, Lo=0H
Pin 2: Ground
Pin 3: High voltage out Voc=18Vdc, Isc=268mA, Co=0.194uF, Lo=495uH
Pin 4: Low voltage out Voc=3.2Vdc, Isc=32mA, Co=100uF, Lo=23.9uH
EnvironmentalStorage temp.: -40°C to 60°C (-40°F to 140°F)
Operating temp.: -20°C to 50°C (-4°F to 122°F)
Ingress protection: Designed to meet IP65
ApprovalsRoHS, CE, RCM
Canada & USA: Class I Division 1 Group A,B,C,D T3; Class I Zone 0 AEx ia IIC T3; Ex ia IIC T3 Ga
IECEx: Ex ia IIC T3 Ga
ATEX: Ex ia IIC T3 Ga
LEL: CSA C22.2 No.152; ISA 12.13.01
FCC ID: W77EXO IC: 8255A-EXO
Contains: FCC ID: XPY1EIQ24NN, Q639603N
IC: 8585A-1EIQ24NN, 4629A-9603N
WarrantyThree-year hardware warranty
Extended warranty available

G6

G6

Transforming single-gas detection with cloud connectivity.

Streamline incident response, improve safety and compliance, and boost gas detector available. G6 gives you vital and up-to-date worker location and safety status information for quick and informed action to get ahead of risks. Lower cost & increased operational efficiency through fewer lost devices & IT infrastructure. Real-time visibility into the safety and status of worksites to build more informed, data-rich operations. Easy-to-use and intrinsically safe device with minimal maintenance and unmatched reliability with a four-year life span and a rechargeable battery that can last up to one year.

Features

  • Direct to cloud connectivity
  • Integrated GPS technology
  • Single-gas detection
  • Rechargeable battery
  • Emergency SOS
  • Usage compliance & gas exposure reporting
Standard features Emergency SOS Find My G6 Over-the-air configurations Automatic over-the-air firmware updates Automatic bump tests and calibrations through G6 Dock Location Beacon support
Gas monitoring features Single-gas monitoring – CO, H2S, O2, or SO2 Live gas on display High gas notification Low gas notification Sensor over limit (OL) notification Sensor under limit (UL) notification Short-term exposure limit (STEL) notification Time weighted average (TWA) notification Bump test and calibration notification Bump test and calibration failure notification
Size & weight

Size: 71mm x 110mm x 37mm (2.8” x 4.3” x 1.5”) Weight: 146g (5.2 oz)

User interface 240 x 320 pixel graphical, high contrast, 6-bit color liquid crystal display Menu system and power-on driven by three button keypad Multi-language support: EN, FR, ES, DE, IT, NL, PT
User notification Visual: Color display and multi-color lights on top and side Sensory: Vibrating Audible: ~95 dB @ 30 cm (11.8”)
Power & battery Rechargeable Li-ion battery: 1200 mAh Battery life: Up to 12 months at 20°C (68°F), depending on configuration, service plan and use Charge time: 4 hours
Approvals SAR, RoHS, CE, RCM Contains FCC ID: W77BLG6C1 IC: 8255A-BLG6C1 FCC ID: XF6-B001P4V2P1, IC: 8407A-B001P4V2P1 Canada & USA: Class I Division 1 Group A,B,C,D T4; Class I Zone 0 AEx da ia IIC T4; Ex da ia IIC T4 Ga IECEx: Ex da ia IIC T4 Ga ATEX: Ex da ia IIC T4 Ga UKCA: Ex ia IIC T4 Ga
Location technology GPS Radio: 48-channel high sensitivity Assisted-GPS: Yes GPS Accuracy: ~5 m (16 ft) Outdoors Location update frequency: During high urgency events and every 5 minutes to 6 hours, depending
Cellular communcation LTE-M and NB-loT
Environmental Storage temperature: -30°C to 60°C (-22°F to 140°F) Operating temperature: -20°C to 55°C (-4°F to 131°F) Charging temperature: 0°C to 45°C (32°F to 113°F) Ingress Protection: Designed to meet IP67
Warranty CO, H2S, O2: Four-year limited warranty SO2: Two-year limited warranty
Blackline Live web application Cloud-hosted safety monitoring web application is customizable for every customer requirement Includes compliance dashboard, map, user roles, device configurations, notification setups, and essential reporting

Loner Mobile App

Loner mobile with SOS button

Turns your Apple or Android smart phone into a lone worker device. Prior to entering a site, building or client’s home, lone workers can send location-based notes to monitoring infrastructure that provide valuable context surrounding their location, activities and risk level. A configurable check-in timer confirms the Lone Workers ongoing well-being and notifies the Guardian Angel monitoring centre of exceptions via safety alerting. If an emergency incident occurs, the user can trigger a Loner Mobile’s SOS alert to notify Guardian Angel monitoring personnel immediately.

Loner Mobile leverages Blackline’s SOS Button accessory, which features Bluetooth® Smart communications and pairs with a smartphone’s Loner Mobile app. The SOS Button is the critical physical interface used to instantly call for help without the need to have your phone in your hand. All safety incidents are communicated to Guardian Angel monitoring personnel through Loner Mobile app.

Features

  • Two-way voice
  • 24/7 live monitoring
  • Automated check-ins
  • Custom notes
  • Emergency alerting
  • Location technologies
  • Blackline Live portal
  • Wearable accessories
Smartphone CompatibilityiPhone: iOS 8.0.1+
Android: 4+
BlackBerry: OS 10+
Safety monitoring featuresEmergency alert: slider control within application
Worker check-in: configurable check-in period (1 – 180 min)
Automatic check-in on GPS speed (configurable above 20 km/h)
Additional features via optional Loner Duo accessory

SOS Latch: open latch to trigger alert
Silent SOS: press & hold acknowledge button to trigger alert
No-motion detection using internal accelerometer

Additional features via optional SOS Button

SOS Alert: easily trigger an alert by pushing the button Connection status: red and green lights clearly indicate connection status | Can be worn as a pendant, like a wrist watch or with a clothing clip (pants pocket, belt, shirt placket or pocket)

Two-way voice calling

Upon triggering of an SOS Alert, Loner Mobile automatically phones a specified number

Employee check-ins

Check in upon Loner Mobile request or early with a press of a button (Loner Duo or SOS Button). Early check-ins with Loner Duo and SOS button do not require unlocking the smartphone.

Notes

Optional check-in note: pre-defined or custom note, includes employee location

User Notification

Indicators: alarm, sound and vibration notifications

Location technology

GPS accuracy: ~5 m (16 ft) outdoors
Wi-Fi accuracy: ~25 m (82 ft)
Mobile network accuracy: ~1500 m (4900 ft)

Mobile messaging methods

Email, text message (SMS)

Alert messages

SOS Alert, Missed Check-in, Low Battery, Power Off

Location publishing

Periodic automatic location reporting: 1 – 60 minutes | Hybrid of: GPS, Wi-Fi and mobile network tower ID

Compliance

BS 8484 compliant

Device requirements

Installation on compatible smartphone, activation within Blackline Live, service plan, GPS or Wi-Fi coverage for locating, cellular communications

Wireless coverage & activated service plans

Wireless coverage: Depends on wireless carrier

Blackline Live web application

Features Include: Alarm banner, event history, device location mapping, device management, alert & notification settings and more
Comprehensive safety alert lifecycle management: includes alert configuration profiles, safety protocol, and emergency contacts

Indoor Locating Beacons

Location beacon

Location Beacon augments location transmissions where GPS alone may not be sufficient. Installed inside and around facilities, beacon transmits location signals for proximity detection with a Blackline safety monitoring device.

Beacon works together with optional floor and site plans that are uploaded into the Blackline Live portal by mapping an employee’s location in context of their surroundings and delivering comprehensive situational awareness in and around complex facilities. In addition, Location Beacon provides a configurable power-level that accommodates different positioning resolution needs.

Features

  • Intrinsically safe
  • Precise location technology
  • Floor plans and location names
  • Long battery life
  • IP65 sealed
  • Easy setup
  • Compact design
Size & weightSize: 161 mm H x 40 mm W x 32 mm D (6.4” x 1.6” x 1.3”)
Weight: 210 g (7.4 oz)
MountingMounting bracket included
Mounting methods: screws, tie straps, adhesive
Mounting options: walls, wall corners, poles, etc.
Buttons & indicator lights

Single button for powering on/off plus configuration Green LED for power indication and configuration Red LED for low battery indication

Wireless communication

Indoor positioning radio: 2.4 GHz to supported Loner safety monitoring devices

Location technology

Low-power continuous beacon signal enables Loner safety monitoring device proximity detection

Beacon signal range

Four configurable signal range levels between 4.5 m and 36 m (15 ft and 120 ft) line of sight (less range when obstructed)

Notification messages

Low Battery communicated by Loner or G7 devices

Power & battery

Batteries: two C-cell alkaline (included)
Battery life: 5 years continuous operation at highest power setting, no wiring required

Environmental

Storage temperature: -40 to 65° C (-40 to 149° F)
Operating temperature: -20 to 55° C (-4 to 131° F)
Ingress Protection: IP65

Regulatory compliance

Class I, Div 1, Groups A-D, T4
ATEX: II 1G, Ex ia IIC T4 Ga
IECEx: Ex ia IIC T4 Ga
RoHS
FCC ID: W77BCN
IC: 8255A-BCN

Device requirements

Blackline Live Portal user account with activated, compatible Loner or G7 devices

Warranty

One year limited factory warranty

Wireless coverage & activated service plans

2.4 GHz operation regions: global
Service plan options: no service plan required

Blackline Live web application

Features Include: Beacon map editor, alarm banner, event history, device location mapping, device management, alert & notification settings and more
Comprehensive safety alert life cycle management:includes alert configuration profiles, safety protocol, and emergency contacts

Blackline Live

Blackline Live

Blackline Live is a leading cloud-based platform that equips businesses with world-class tools to manage their safety devices, monitor their workforce and facilities’ wellbeing, respond to emergencies and report on data collected. SOC2 Type 1 compliant, Blackline Live can be accessed from anywhere on an internet-connected device, so you don’t need to be on-site to know how your team is doing.

Features

  • Alert management tools
  • Custom maps & floor plans
  • Custom alert profiles
  • Wireless device configuration
  • Single sign-on (SSO) functionality
  • User roles & access controls
  • Compliance dashboard
  • Analytics reports

LIVE LOCATION DATA: Used by Blackline’s in-house Safety Operations Center (SOC) and alarm receiving center partners around the world, Blackline Live’s real-time maps provide a live view of the ongoing safety of an organization’s team members and facilities. Powered by data streamed from devices in the field, the maps actively update so teams can quickly view the location and alert status of all their G7 person-worn and G7 EXO area gas monitors.

FUNCTIONAL DEVICE CONFIGURATION: G7 and G7 EXO devices are easily configured for specific work environments using configuration profiles. Updates and firmware changes are pushed wirelessly, over-the-air, ensuring devices are always up-to-date and working as they should.

CUSTOM ALERT PROFILES: Alert profiles are also configured through Blackline Live, with documented custom emergency protocols that instruct monitoring personnel how to manage emergency responses according to a business’ unique needs. Alert profiles provide monitoring personnel with critical work flows to manage alerts in real-time.

AUTOMATED REPORTING: A series of live graphs and charts provide teams with an at-a-glance summary of their fleet health, including usage and device testing information. Supporting gas detection programs, G7c, G7x and G7 EXO devices equipped with a gas sensor cartridge wirelessly communicate bump test and calibration data to Blackline Live for automated reporting, alleviating the potential risk of human error and the need for manual data collection.

SECURITY & AUTHENTICATION: Offers convenient single sign-on (SSO) option through Security Assertion Markup Language (SAML) 2.0. Further, if your Identity Provider (IDP) offers multi-factor authentication (MFA), then your employees can also use the secure MFA to authenticate with Blackline Live. And, you can control their access to our services without needing to go into Blackline Live.

We know Blackline safety

We’ll help you choose the right product to protect your people.

lone and remote workers safety device Buyers Guide

Not sure what you need?

Get your FREE copy of the Buyers Guide

“How to Evaluate Lone & Remote Worker Solutions”

Learn how to select the right devices, monitoring & get clarity on the best lone & remote worker solutions for your organisations needs.

Our clients include

Delivering Lone Worker solutions for leading brands
